Wondery Servo Aluminum Radiator Crimping Machine 1050mm Core Height

Name: Wondery Servo Aluminum Radiator Crimping Machine 1050mm Core Height
Brand: Wuxi Wondery Industry Equipment Co., Ltd
Price: 25.00 USD
Availability: InStock

Marchio:	WONDERY
Moq:	1
prezzo:	$23,000-27,000

Informazioni Dettagliate

Descrizione del prodotto

Informazioni Dettagliate

Luogo di origine:

Jiangsu

Peso:

3200 kg

Altezza del nucleo:

1050 mm

Larghezza del nucleo:

1000 mm

Spessore massimo:

120 mm

Denti piegati:

100 pezzi

Alimentazione elettrica:

AC-220V; 50Hz

Dimensioni:

2400 × 2200 × 2200mm

Sistema di controllo:

PLC e touchscreen

Commutatore di prossimità:

Omron, Giappone

Guida lineare:

TBI, Taiwan

Componenti pneumatiche:

Airtac, Taiwan

PLC e HMI:

Delta, Taiwan

Servo motore:

Delta, Taiwan

Contattore:

Schneider, Cina

Principio di lavoro:

spingendo, premendo e conquistando

Evidenziare:

aluminum radiator crimping machine

servo radiator fin machine

1050mm core height crimper

Descrizione del prodotto

Servo Type Aluminum Radiator Plastic Tank Crimping Machine

High Efficiency Crimping Solution

The aluminum radiator plastic tank crimping clinching machine is designed for crimping the teeth of header plates and securely locking plastic tanks to the core body. This creates a sealed space between the crimped plastic tank, sealing gasket, and header plate. Our servo-controlled machine handles products of various specifications with precision and efficiency.

Key Features

PLC controlled with HMI screen for easy operation
Servo and pneumatic power system for automatic 4-side clinching
Automatic dodging function to prevent collision with water pipes
Programmable for different radiator specifications
Quick-change clinching tools for different tank sizes
Comprehensive safety features including alarm lamp and photoelectric sensors

Technical Specifications

Specification	Value
Max core height	1050mm (customizable)
Max core width	1000mm (customizable)
Maximum thickness	120mm (customizable)
Max crimped teeth quantity	100 pieces
Power supply	AC-220V, 50Hz
Dimensions	2400×2200×2200mm
Weight	Approx. 3200kg

Premium Components

Proximity switch: Omron, Japan

Linear guide and ball screw: TBI, Taiwan

Pneumatic components: AIRTAC, Taiwan

PLC and HMI: Delta, Taiwan

Servo motor & driver: Delta, Taiwan

Electrical components: Schneider, China

Operation Highlights

Precise crimping program setup via touch screen interface
Real-time working status monitoring
Separate long-header and short-header crimping devices
Advanced movement capabilities including dodge and step-forward moves

About Wuxi Wondery Industry Equipment Co., Ltd.

We are a professional supplier of industrial machines serving various industries including automotive, HVAC, and power generation. Established in 2008, we specialize in radiator manufacturing equipment and offer comprehensive services including technical consultation, installation, training, and maintenance. Our machines have been exported worldwide to countries including USA, Australia, Mexico, India, and many others.

Frequently Asked Questions

What is the power supply requirement?

The power supply can be adjusted to match your local requirements through a transformer or direct voltage matching.

What information is needed for quotation?

Please provide technical requirements, drawings, pictures, industrial voltage, and planned output.

What are the payment terms?

40% down payment, 60% before delivery (T/T transfer).

What is the delivery time?

30-60 days after receipt of down payment.
